Ball Valve F Water Meter Console, PN30

Description

Angled ball valve with Tea coated ball, internal x external thread and knob. Area of use: Tap water. Material: Dezincification-resistant brass. Working temperature: -10°C/+100°C. Max working pressure: PN 30.

Technical Information

• Dimension: G20x25
• Pressure/Flow/Temp : PN30
• External pipe diameter connection 1 : 22 mm
• Dimension connection 1: DN 20
• Dimension connection 2: DN 20
• Connection 1 : Clamping ring
• Connection 2 : Internal thread Rc, conical (ISO 7-1 / EN 10226-1)
• Fireproof : Yes
• Construction length connection 1 (Z1) : 100 mm
• Construction length connection 2 (Z2) : 70 mm
• Length of connection 1 : 17 mm
• Length of connection 2 : 14 mm
• Handle height: 14 mm
• Length of handle : 70 mm
• House construction: 2-part
• Operation : Handle/Lever
• Material ball seal : PTFE (polytetrafluoroethylene)
• Material spindle seal, primary : PTFE (polytetrafluoroethylene)
• Material spindle seal, secondary : PTFE (polytetrafluoroethylene)
• Material quality : Brass dezincification resistant (DZR)
• Max. differential pressure at 20°C: 16 bar
• Max. medium temperature (continuous) : 100 °C
• With coupling connection 1 : Yes
• With coupling connection 2 : Yes
• My. medium temperature (continuous) : 2 °C
• Model/Version : Right-angled
• Seal : PTFE (polytetrafluoroethylene)
• External pipe diameter connection 2: 20 mm
• Valve angle : 90 °

Specifications

• Function: knob
• Design: internal/external thread
• Colour: grey
• Surface treatment: nickel-plated
• Material: dezincification resistant brass
